Product Specifications
Dual or single CPUs in a single slot solution
Motorola 68040/68060 architecture
· 23-66 MHz CPU speeds
128 MB high-speed DRAM
Up to 16 MB Flash
10/Base-T Ethernet
Exclusive, high speed EZ-Bus mezzanine interface
Full line of EZ-Bus mezzanine cards
The V452 provides you with either single or dual '060/'040 processors. It's exclusive EZ-Bus mezzanine system provides the highest-bandwidth mezzanine card interface available on a 68K CPU-based card. Synergy provides a full range of I/O modules upporting EZ-Bus. Features include single or dual 50/66 MHz 68060s or 25/33 MHz 68040s, 50% power reduction over other 68K boards, ruggedization options, up to 128 MB DRAM, up to 16 MB flash, Bellcore,Nynex compliance, 10Base-T Ethernet, VME64 extensions support, EMI and conformal coating options.
SKUE-AD
Qty 1
Alternative P/N #: V452, V 452, 0090-76133-A,
Product Manual
Product Images
