Product Specifications
800 MHz or 1.2 GHz Freescale QorIQ™ P2010 or P2020 processor based 6U VME board
1GB or 2GB DDR3-800, soldered down
Three on-board Gigabit Ethernet interfaces (one front, one rear, one configurable by customer to front or rear)
Five serial ports
One USB 2.0 port
One PCM/XMC site
Optional rear transition module
Hard drive mounting kit available
Extended temperature (-40 °C to +71 °C) and rugged variants
800 MHz Freescale P2010 single-core processor
1.2 GHz Freescale P2020 dual-core processor
512 KB L2 shared cache
Integrated, on-chip controllers for DDR2/3, PCI Express, USB 2.0, DUART, 10/100/1000 Ethernet, DMA, SDHC, SPI flash, I2C and security acceleration
Single channel 800MB/s
1 GB or 2GB DDR3-800, soldered down
512 KB MRAM (NVRAM)
SDHC socket
16MB SPI Flash (2x 8MB)
Manufactured by Artesyn. Refurbished in good condition.
The Artesyn Embedded Technologies MVME2500 single-board computer (SBC) features the Freescale QorIQ™ P2010 or dual-core P2020. The e500 v2 core QorIQ processor uses 45 nanometer technology, which delivers an industry-leading performance-to-power ratio with single-core or dual-core frequencies up to 1.2 GHz at less than 8W. This is a perfect migration path for our PowerQUICC processor boards (MVME3100 and MVME4100), as well as our G4 processor boards (MVME5100 and MVME5110). On-board memory includes up to 2GB DDR3 memory and 512 KB non-volatile magneto resistive random access memory. MRAM is high speed non-volatile RAM with unlimited read/ write access that protects data in the event of a power loss and does not require periodic
refresh. MRAM is ideal for critical non-volatile data storage, data logs, dynamic program updates, and dynamic security. Connectivity includes Gigabit Ethernet, USB 2.0, serial ports, SATA port and one PMC/XMC site. A hard drive mounting kit is available for Serial ATA or solid state hard drives. The extended temperature models feature an operating temperature range of -40 °C to +71 °C – a significant increase over the standard models’ 0 °C to +55 °C range. Acceptable storage temperatures have also been increased, safely accommodating environments from -50 °C to +100 °C. The rugged variants are capable of operating under up to 5G of vibration (15 to 2000 Hz) and can withstand an 11 millisecond shock of up to 30G. Conformal coating is also available. The MVME2500 is ideal for automation, medical, and military applications such as railway control, semiconductor processing, test and measurement, image processing, and radar/sonar.
Transition Modules
The MVME7216E transition module provides industry standard connector access to two 10/100/1000BaseTX ports, and four asynchronous serial ports configured as RS-232 DTE. All of these are via RJ-45 connectors. The MVME7216E RTM is designed to directly connect to the VME backplane in chassis with an 80mm deep rear transition area. This transition module is compatible with the MVME3100, MVME4100 and MVME7100 boards.
SKUE19-1
Qty 1
Alternative P/N: 8406822H61E, MVME2500, MVME 2500, MVME2500, MVME- 2500
