Product Specifications

• Boot / Run any OS in a Single Slot
• PCI 32-Bit at 33/66 MHz
• 2.5” SSD Media to 16 GByte
• Rotating Media from 10 GByte to 160 GByte
• CompactFlash from 512 MByte to 16 GByte
• Hard Drive Memory: 8 GB - 160 GB HDD*
• Drive Types: 2.5" Rotating Media / Solid State Media / Extended Duty*
• Drivers Supported: 1

The GE Fanuc / Ramix PMC-24x Series High Capacity Disk Storage provides a single PCI Mezzanine Card (PMC) slot storage solution utilizing industry standard rotating and solid-state disks. Designed to be plugged onto a host processor [or Single Board Computer (SBC) card], these products provide an extremely compact, flexible and economical high performance storage solution that will mount on any PMC location, either directly on a processor card or on a PMC carrier board.

The PMC24x family of embedded disk modules offers a high performance, cost effective option for file system and boot storage. Combining high performance controllers developed for high-end workstations with disk technology used in laptops, the PMC243 delivers very high data rates in a compact form factor implemented with components designed for physically demanding environments. Other members of the PMC24x family (such as PMC244) utilize Compact Flash storage devices providing media portability. With the PMC24x "single slot", computing solutions, the user does not need to compromise in either capacity or performance.

Alternative Part No.PMC-24x Series, PMC243, PMC 243, PMC-243, PMC244, PMC 244, PMC-244, PMC245, PMC 245, PMC-245
