Product Specifications

• ULV Intel® Celeron® 400/650 MHz Fanless, LV Pentium® III 800/933 MHz
• Chipset: VIA® VT8606/TwisterT and VT82C686B
• VGA/LCD controller with optimized Shared Memory Architecture (SMA)
• Four AGP VGA/LCD & LCD controller up to 1024 x 768
• +5 V and +12 V power supply required
• 10/100Mbps PCI Ethernet interface, supports Wake-on-LAN
• PC/104 and PC/104-Plus expansion connector
• Support for CompactFlash® Card (CFC) Type I Socket
• One SODIMM socket supports up to 512 MB SDRAM

The Advantech PCM-3370 utilizes a PC/104+ form factor design that supports ULV Celeron 400/650 processors and LV Pentium III 800, 933 processors. This effective PC/104+ solution gives end users the choice of good, economical performance with the ULV Celeron series processors, or the impressive performance of the LV Pentium III series. These processor flexibility combined with all the other on-board features, explains why the PCM-3370 is the new top-of-the-line PC/104+ CPU module solution at Advantech. The PCM-3370 is loaded with special on-board features that rival full-size systems. It has standard 10/100Base-T PCI Ethernet, 36-bit DSTN/ TFT LCD panel support as well as SSD support for CompactFlash. There is PC/104 and PC/104+ socket for optional international version. The PCM-3370 also includes 1 SODIMM sockets for up to 512MB total onboard memory. The PCM-3370 was designed using feedback and knowledge gained from
our customers. It has more of the features our customers have requested. It is 100% PC compatible and is ready to handle the most challenging customer driven environments. Besides the great onboard memory flexibility and capacity, the PCM-3370 has four on-board serial ports, each
with +5 V power, two USB connectors, watchdog timer and tough industrial grade construction. The Award 256 KB Flash BIOS supports Plug & Play, Boot from Ethernet, Boot from CD-ROM, Boot from Zip drive, Wake-on-Lan, Modem and LCD backlight turnoff. All these features make the PCM-3370 a very "system integrator friendly" solution, perfect for handling medical, DVR, Industrial automation and transportation applications in the harshest unmanned environment

Alternative Part No. PCM-3370F-R0A1E, PCM-3370F-M0A1E, PCM-3370F-J0A1E, PCM-3370Z-J0A1E, PCM-3370E-M0A1E, PCM-3370E-J0A1E
