VSBC-32 PEP MODULAR COMPUTERS

$0.00

32-Bit Single-Board Computer

32-Bit Single-Board Computer

Product Specifications

  • HIGHPERFORMANCE CPUs SINGLE-BOARD COMPUTERS

  • QUad-channel Integrated

    Communications Controller

  • Up to six serial interfaces

  • serial Interfaces accessible by front-panel and CXC

  • Flexible front-Panel options for network and Serial I/O

  • CXC Interface

  • Up to 64 MByte DRAM & 4 MByte FLASH

  • Implemented background debugging

  • low power consumption

  • extended operating temperature range capability

  • extensive software support

  • cE conformance

  • Manufactured by PEP Modular Computers.

  • used in good condition.

TA VMEbus single-board computer incorporating the 32-bit MC68(EN)360 high-performance QUad-channel Integrated Communications Controller (QUICC). First introduced in 1990, PEP’s Controller eXtension Connector (CXC) concept enables a mezzanine I/O extension according to the guidelines laid-down in the CXC specification.PEP has named these Mezzanine plugin units ‘Controller eXtension Modules’ (CXMs).These 96-pin CXMs are designed to operate with CXC-based host CPU modules which includes the VSBC-32. Designed primarily to operate in harsh industrial environments, this versatile modularity provides not only a cost-effective engineering solution but also allows customers a near exhaustive selection of system configurations through a portfolio of over 30 CXMs providing analog, digital and other I/O extensions such as SCSI and fieldbus connection (High-speed PROFIBUS,CAN, LON and Interbus-S.) Hence, a feature of the VSBC-32 is that the ‘raw’ serial signals from the ‘QUICC’ SCC2, SCC3 and SCC4 channels, being internally wired to the CXC interface,may be used by dedicated signal translation modules. Network interfacing is provided if required by ordering the relevant front-panel which comes complete with the appropriate SI-piggyback and serial port connectors. Naturally, to cater for those customers who merely wish to take advantage of the communication power and CXC capablility that the VSBC-32 offers, blank frontpanels without the networking options have been devised. Wind River’s VxWorks distributed real-time operating system includes integrated networking facilities and a complete software development environment for Windows and UNIX hosts such as high-end PC and SUN Workstations. Major features of VxWorks include a fast, multitasking kernel with preemptive scheduling and fast interrupt response, extensive intertask communications and synchronisation facilities, efficient UNIX-compatible memory manage-ment, multiprocessor facilities, a shell for user interface, symbolic and source level debugging capabilities, performance monitoring and an I/O file system.

SKUE17

Qty 1

Alternative Part No. VSBC-32-BASE, DM600, DM601, DM602, DM603, DM604, DM605, SI-10B2, SI-10B5, SI-10BT, SI-DUMMY, SI-PB232, SI-PB232-ISO, SI-PB485-ISO, CABLE-VM42

Product Manual

VSBC-32 Datasheet
