Product Specifications
• Intel® Core™2 Duo processor LV,
1.5 GHz
• Intel Core Duo processor 1.66
GHz and 2.0 GHz
• Ultra compact, two slots
• Extensive software support
• Up to 4 Gbyte DDR2 SDRAM
(200MHz) with ECC
• Flash Drive or local UDMA2
(ATA33) 2.5” hard disk
• 2x SATA, RAID 0/1 capable
• Front/rear VGA up to 1280x1024,
rear DVI-I up to 1280 x 1024, 32
Mbyte RAM
• Two Gigabit Ethernet ports
10/100/1000 BaseT front or rear
optional
• Compliant to VITA31.1-2003
• One front Fast Ethernet port
• Two PMC extension slots, one 64-
bit/133 MHz and one 32-bit/33
MHz
• One XMC interface on request
• 2x serial I/O with FIFOs
RS-232/422/485 interface
• 4x USB 2.0 ports, two front and
two on rear
• Audio codec
• Watchdog, temperature sensors
• Optional –40 °C to +75 °C
• Optional conformal coating
• Customer specific, low cost
assembly versions
• RoHS compliant
Manufactured by SBS Technologies/GB/Abaco. New- Excellent.
The VP11 is a 6U VME64 CPU board with integrated dual core Intel Core 2 Duo Processor or Intel Core Duo Processor and dual Gigabit Ethernet channels. The Intel dual core processor includes two optimized execution cores in a single processor case. This enables execution of parallel threads or applications on separate cores with dedicated CPU resources. The VP11 supports a 32- and 64-bit processor architecture. The VP11 is designed to meet the requirements of markets such as automation, simulation/training, test and measurement, and others.
SKUE34
Qty 1
Alternative Part No. VP11, VP1107C26RF1
