Product Specifications
• Up to 2.0 GByte DDR2 SDRAM (One SODIMM)
• SVGA port (front I/O)
• Dual Gigabit Ethernet (GbE) (front I/O)
• One RS232/422 COM port (front I/O)
• One RS232/422 COM support (rear I/O)
• Two USB 2.0 ports (front I/O)
• Four USB 2.0 support (rear I/O)
• Supports two SATA connections (rear I/O)
• One 2.5-in. SATA hard drive (optional for V7769 only)
• Dual SAS connector (front I/O on V7769 only)
• Real-Time clock/calendar
• Front panel reset switch
• PS/2 Keyboard/Mouse connection (front I/O)
• Onboard parallel connector
The V7768/V7769 Manufactured by Abaco Systems, formerly GE Fanuc/VMIC, are suitable for use in a variety of applications, such as:telecommunications, simulation, instrumentation, industrial control, processcontrol and monitoring, factory automation, automated test systems, data acquisition systems and anywhere that the highest performance processingpower for VME in a single or dual slot is desired. The V7768/V7769 incorporate the latest Intel chipset technology, the 945GM. The Intel 945GM chipset is an optimized integrated graphics solution with up to a 667 MHz system bus. The chipset has a low power design, vanced power management, supporting up to 2 GByte of DDR2 system memory. The 945GM is a Memory Controller Hub (MCH) component, providing the processor interface, system memory interface (DDR2 SDRAM) and SVGA port. The V7768/V7769 provide front panel access for the PMC xpansion site, an optional Gigabit Ethernet port, one 10/100 RJ45 connector, one serial port, SVGA, keyboard/mouse, the manual reset switch and the status LEDs.
Alternative Part No. vMIVME7768, VMIVME 7768, VMIVME-7768, V7768, V7769, VME7768, VME 7768, 350-9301007768-320001
