Product Specifications
Choice of processors: 32 MHz MC68040 enhanced 32-bit microprocessor with 8KB of cache, and MMU and FPU;
or 25 MHz MC68LC040 enhanced 32-bit microprocessor with 8KB of cache and MMUA32/D64 VMEbus master/slave interface with system controller function
High-performance DMA support for VMEbus D64 and
local bus memory burst cycles
16MB of configurable SDRAM
512KB SRAM with battery backup
1MB Flash memory for on-board monitor/debugger or user-installed firmware
8K x 8 NVRAM and time-of-day clock with battery backup
Two serial communication ports, console port as EIA-232-D DCE and second port user configurable for EIA-232-D/EIA-422 (V.36) DTE/DCE
Four 16- or two 32-bit IndustryPack® ports with one DMA channel per port
Optional SCSI and Ethernet interfaces
Six 32-bit timers, one watchdog timer
The MVME162P4 family provides OEMs and solutions developers an ideal platform for embedded monitoring and control applications. It allows an OEM to minimize engineering expenses while integrating value-added hardware and software applications onto an off-the-shelf product. In order to provide this wide range of solutions, the MVME162P4 allows a variety of MPU, memory and interface options such as floating point, Ethernet, SCSI and VME. The result is a variation of the MVME162P4, which most closely fits the application requirement. The inclusion of the new “Petra” application-specific integrated circuit (ASIC), which replaces functions formerly implemented in the IP2 chip, MC2 chip and MCECC chip, improves the performance of the memory subsystem. Memory configuration switches enable the customer to tailor memory size for applications requiring smaller memory configurations.
Alternative Part No. MVME162-410, MVME162-411, MVME162-412, MVME162-413, MVME162-430, MVME162-431, MVME162-432, MVME162-433, MVME162-453, MVME162-510, MVME162-511, MVME162-511A, MVME162-512, MVME162-513, MVME162-520, MVME162-521, MVME162-522, MVME162-523, MVME162-530, MVME162-531, MVME162-532, MVME162-533, MVME162-012A, MVME162 410, MVME162 411, MVME162 412, MVME162 413, MVME162 430, MVME162 431, MVME162 432, MVME162 433, MVME162 453, MVME162 510, MVME162 510A, MVME162 511, MVME162 512, MVME162 513, MVME162 520, MVME162 521, MVME162 522, MVME162 523, MVME162 530, MVME162 531, MVME162 532, MVME162 533, MVME162 012A, MVME162410, MVME162411, MVME162412, MVME162413, MVME162430, MVME162431, MVME162432, MVME162433, MVME162453, MVME162510, MVME162511, MVME162512, MVME162513, MVME162520, MVME162521, MVME162522, MVME162523, MVME162530, MVME162531, MVME162532, MVME162533, MVME162012A, MVME162-223, VME162PA-244LSE, VME162PA 244LSE, VME162PA244LSE, MVME162220, MVME162-21
