Image 1 of 1
Price: Contact Us
Email: sales@esi-technologies.com
Condition: USED IN GOOD CONDITION
Location: SKUE3
In Stock: 2
Product Specifications
16, 25, or 33.33 MHz MC68030 enhanced 32-bit microprocessor
16, 25, or 33.33 MHz MC68882 floating-point coprocessor
4, 8, 16, or 32MB of shared DRAM, with programmable parity
4K x 8 SRAM and time-of-day clock with battery
Four 28/32-pin ROM/PROM/EPROM/EEPROM sockets, 16-bits wide
A32/D32 VMEbus master/slave interface with system controller function
Four EIA-232-D serial communications ports
Centronics® compatible printer port
Two 16-bit timers and watchdog timer
SCSI bus interface with DMA
Ethernet transceiver interface
4-level requester, 7-level interrupter
7-level interrupt handler for VMEbusOn-board debugger and diagnostic firmware
The MVME147 series offers one of the world’s finest VMEbus single-board computers. The on-board resources and peripheral controllers eliminate the need for additional modules in the VMEbus backplane thus reducing costs and freeing up valuable bus slots for additional functions. The MVME147 series features an MC68030 enhanced 32-bit microprocessor. The MC68030 was the first general purpose microprocessor with on-chip cache memory for both instructions and data which increases the processor’s efficiency by 20 to 40 percent. The MC68030 features a complete memory management unit (MMU) which provides the software protection and virtual memory functions critical to many applications.
Transition Modules:
Optional MVME712 series transition modules are available to support the use of standard I/O connections for the MVME147 series. These modules take the I/O connections for the peripherals on board the MVME147 series from the P2 connection of the module to a transition module that has industry standard connections
Development Software:
for the MVME147 series includes the on-board debugger/monitor firmware and driver packages for the UNIX® SYSTEM V/68 and VMEexec® environments. Debugger/monitor firmware is included on the board.
Alternative Part No. mVME147 013,mVME 147 013, MVME 147-010, MVME 147-011, MVME 147-012, MVME 147-013, MVME 147-014, MVME 147-022, MVME 147-023, MVME 147-024, MVME147-010, MVME147-011, MVME147-012, MVME147-013, MVME147-014, MVME147-022, MVME147-023, MVME147-024, MVME-147-010, MVME-147-011, MVME-147-012, MVME-147-013, MVME-147-014, MVME-147-022, MVME-147-023, MVME-147-024, MVME 147 010, MVME 147 011, MVME 147 012, MVME 147 013, MVME 147 014, MVME 147 022, MVME 147 023, MVME 147 024, MVME147 010, MVME147 011, MVME147 012, MVME147 013, MVME147 014, MVME147 022, MVME147 023, MVME147 024, MVME-147 010, MVME-147 011, MVME-147 012, MVME-147 013, MVME-147 014, MVME-147 022, MVME-147 023, MVME-147 024, MVME 147010, MVME 147011, MVME 147012, MVME 147013, MVME 147014, MVME 147022, MVME 147023, MVME 147024, MVME147010, MVME147011, MVME147012, MVME147013, MVME147014, MVME147022, MVME147023, MVME147024, MVME-147010, MVME-147011, MVME-147012, MVME-147013, MVME-147014, MVME-147022, MVME-147023, MVME-147024, MVME147A-1, MVME147A1, MVME147A 1, MVME147 A-1, MVME147 A1, MVME147 A 1
Product Manual
Product Images
