Product Specifications
Functionality: It provides 24 lines of digital input/output (I/O) for industrial automation and process control applications.
Configuration: Each of the 24 lines can be individually configured as an input or an output.
Compatibility: The module conforms to the IndustryPack Interface Specification, ensuring compatibility with various support modules.
Supports 16-bit word, 8-bit byte, or bit operations.
Includes read-back and loop-back registers for software convenience.
The industry standard 50-pin interface cable can be connected to screw terminal blocks or OPTO-22 interface modules.
Manufactured by Greenspring, Abaco Systems, and SBS. Refurbished in good condition.The Greenspring IP-Digital24 24 Line Digital I/O IndustryPack Module is part of the Industry Pack family of modular I/O components. It provides 24 lines of digital I/O. Each line may be individually set as input or output. Both read-back and loop-back registers are provided for maximum software convenience. 16-bit word, 8-bit byte, or bit operations (as read-modify-write) are supported. The IP-Digital 24 conforms to the Industry Pack Interface Specification. This guarantees compatibility with multiple Support Modules. Because the IPs may be mounted on different form factors, while maintaining plug and software compatibility, system prototyping may be done on one Support Module, with final system implementation on a different one. The industry standard 50-pin interface cable may be terminated in a screw terminal block, an OPTO-22 Direct I/O Interface Module, or user-determined hardware.
SKUE26
Qty 2
Alternative Part No. IP-Digital24, IP-Digital-24, IP-Digital 24
