Product Specifications
Technical Information : Jumpers, Connectors, and Memory IOB31 (64-xxx) IO and PCI Express Expansion Board
IOB31 Front View-
Keyboard P7, PS/2 Mouse P8
Parallel Port P5
Serial 1 P1
Serial 2 P2
Flopping drive P4IOB31 Back View-
P6 I/O Expansion Card Connector
PCI Express Edge Connector
LPC47B427
The IOB31 is an I/O expansion module or board, frequently used in conjunction with Trenton System Host Boards (SHBs) and Backplanes. It provides additional Input/Output capabilities, such as supporting PS/2 keyboard functionality, within industrial computer chassis. The IOB31 module is used in specific backplanes (e.g., BPX6806) to enable certain PCIe slot configurations from a PICMG 1.3 System Host Board.
Alternative Part No. 20-XX6475-001, 92-506474-XXXX, IOB31
