Price: Contact Us
Email: sales@esi-technologies.com
Condition: USED IN GOOD CONDITION
Location: SKUE5
In Stock: 1
Product Specifications
Magnification: 0.50 ×
Mount Type: C-mount (microscope side mounts onto Leica 37 mm / ISO 38 mm phototubes
Design Type: Direct Image Projection (DIP)
Microscope Compatibility: Leica Stereo Microscopes (including models like the S6 and S8 APO series)
Parfocal: Precisely machined to maintain focus between the microscope and the TV/monitor.
Low Profile: Positions the camera's CCD chip directly at the intermediate image plane to maximize stability.
Wide Field of View: Provides a broader, clearer viewing area on the monitor compared to standard 1.0 × couplers.
Stereo:
MS5, MZ6, MZ8, MZ12, MZAPO, MZFL3, MZ16
in 37mm port of new phototubes HU(446 174)
video/phototube objective 1.0x (445 930)
video/phototube objective H (445 931)
The Diagnostic Instruments / Spot Imaging Solutions D50MZC is a 0.50 × Direct Image Projection (DIP) C-mount coupler designed for use with 1/2" CCD cameras on Leica stereo microscopes.
It is highly regarded for its low-profile, parfocal design that produces flat field images. D50MZC acts as an optical coupler, specifically designed to relay images accurately from Leica microscope phototubes to C-mount format digital cameras.
The functions as an embedded vision system. The camera is built directly into the drone's structural chassis and communicates with an internal single-board computer, relying on internal microcontrollers to handle continuous input signals.
Alternative Part No. Leica 10445930, D10DMC, D63MZC
