Name: Computer Repair and Sales CP3010. | ESI Technologies, Inc.
Brand: ESI Technologies, Inc.
Availability: InStock

Intel® Atom™ E38xx processors, up to quad-core 1.91 GHz
Up to 8 GB 1333 MHz soldered DDR3L memory
Design optimized for the extended temp. range - fanless up to +85°C
CFast or soldered SATA Flash as boot device
Comprehensive I/O capabilities: DisplayPort, USB 3.0/2.0, Gigabit Ethernet, SATA, CAN, Audio
Main memory:
Up to 8GB Soldered DDR3L running at 1067/1333 MHz, dual channel w/o ECC
Ethernet:
1. Up to three 1000BASE-T interfaces with WOL (Wake-on-LAN) support, two front/rear switchable, third available via
2. 8HP extension, Intel I210-IT Ether controller
2x RJ-45 with integrated LEDs (ACT, SPEED)
Watchdog:
FGPA-based, timeout ranging from 125ms to 4096s programmable in 16 steps, IRQ, reset, dual-stage configuration
USB:
1x USB 3.0 port, 9-pin type-A connector 1x USB 2.0 port, 4-pin type-A connector
The CP3010-SA Kontron's latest low-power 3U CompactPCI® CPU board supports the Intel® Atom™ processors E3826 and E3845 with a maximum of quad-core 1.91 GHz processing performance.
