Product Specifications
Industrial Frame Grabber
1-channel PCI card / frame grabber
Half-size board
Designed for analog vision cameras
3.3-5Vdc from the PCI port
Manufactured by Cognex
Used in Good Condition
Warranty Included
The Cognex® MVS-8510™ Series of machine vision frame grabbers supports the latest high-speed analog camera technology. With a system cost close to that of direct connect cameras, and the bandwidth, reliability, and integrated I/O of a full-featured frame grabber, the MVS-8510 Series is in a price-to-performance class all its own. In addition, these half-slot frame grabbers are backward compatible with legacy analog cameras, while supporting new buses and operating systems. This backwards compatibility makes the MVS-8510 the perfect choice for bringing existing applications forward to the future. Unlike direct connect camera technologies, MVS-8510 frame grabbers provide high-speed image transfer directly to system memory, with minimal CPU impact. This frees the PC host processor for image analysis, motion control and application management. MVS-8510 frame grabbers maximize acquisition speed and efficiency with pipelined processing and on-board image buffering, which allows new images to be acquired while the previous image is being transferred.
SKUE34
Qty 1
Alternative part No. CFG-8511-000,801-8511-1R
