Product Specifications
Extended-life, embedded components provide longevity
22nm Intel Micro-Architecture design (Ivy Bridge-EN) saves power
AltiVec coprocessor for highperformance computational applications
Ten, eight & six-core micro-architecture with Intel Hyper-Threading doubles core processing capability (all ES-2400 vs options)
Intel Turbo Boost Technology (E5-2448L v2, 2418L v2 & 2430 v2 CPUs)
Intel AVX Float 16 supported on all E5-2400 v2 series processors
Native PCI Express Gen 3.0 links support all PCIe devices
System Performance boost with 10, 8, 6-core CPU architecture
On-board power management and system security features
Deployment risks lowered with extended-life board design
On-board interface support for either SAS or SATA/300 drives
Built-in system support for PCI Express 1.1, 2.0 and 3.0 cards
Manufactured by Trenton Systems.
Used in Excellent Condition.
Trenton’s BXTS7059 supports system designs with one x16, two x8 or four x4 PCI Express links on a PICMG 1.3 backplane. These links plus an additional x4 PCIe link (BO) and eight PCIe reference clocks are supplied on SHB edge connectors A & B. Link BO may also function as four, x1 PCIe links. Trenton’s optional IOB33 module can be used on the board to provide additional x4 PCIe expansion link to the system. Upon system power-up, the BXTS7059 automatically configures all the PCIe links between the board and PCIe target devices for optimum data communication. This automatic link negotiation process may result in data transfer communications between the SHB and the system option cards to take place at either PCI Express 3.0, 2.0 or 1.1 link speeds. The actual link speed will be determined by a number of factors such as PCI Express endpoint types, system backplane design and other system design parameters. PCI Express auto-negotiation between the BXTS7059 and the system option cards is fully supported thereby enabling system design support for x1, x4, x8, and x16 PCI Express cards.
SKUE2
Qty 7
Alternative Part No. BXTS7059, 92-507059-xxx, 92-507059-000
