18008–0000– 11–0

$0.00

KONTRON

ETX-P CPU Board

KONTRON

ETX-P CPU Board

Price: ‍ ‍Contact Us

Email: ‍ ‍ sales@esi-technologies.com

Product Specifications

  • Processor
    Intel® Pentium® M processor 1.1 GHz LV and 1.6 GHz Intel® Pentium® M processor 738 LV and 745 Intel® Celeron® M processor 600 ULV and 1.3 GHz

  • Chipset
    Intel 82855GME, 400MHz FSB, integrated graphics

  • DRAM
    1 GByte mx. DDR-SO-DIMM, PC1600/2100

  • Cache
    up to 2MByte 2nd Level

  • Harddisk
    Two enhanced IDE ports Sound AC97 controller, line-input / output and mircophone

  • Video Controller
    Intel Extreme Graphics2 controller, LVDS Flatpanel and CRT output, Up to 32 MByte UMA Video RAM

  • Resolutions
    CRT and LCD max CRT QXGA 2048x1536, max LCD UXGA 1600x1200

  • LCD Panel
    Support Dual Channel LVDS 110 MHz

  • Serial Interfaces
    2x TTL (16550 compatible), IrDA support

  • Enhanced Parallel Port
    shared with Floppy

  • Floppy Port
    shared with LPT

  • Ethernet
    10/100Base-T Intel® 82562 USB 4x

  • USB
    2.0 OHCI ports

  • Expansions
    ETX Interface

  • Dimensions
    95 x 114mm (3.7x4.5“)

  • Power Consumption
    18W @ 5V (1.1 GHz CPU) typ

  • Temperature (*)
    operation: 0° to 60°C, storage: -30° to 85°C

  • Humidity
    operation: 10% to 90%, storage: 5% to 95% (non condensing)

The ETX-PM products feature the Intel® Celeron® M Processor or Intel® Pentium® M Processor with the unique Enhanced Speed Step™ technology. The ETX-PM modules offer supreme computing performance at extreme low power consumption. Supporting up to 1Gbyte of DDRSDRAM technology the memory bandwith is no longer the performance bottleneck. The integrated Intel Extreme Graphics 2 video controller offers resolutions up to 2048x1536 pixel with 2D and 3D acceleration. The JILI display interface technology ensures automatic setting of the video controller parameters for the attached LCD panel. The 4 USB channels support USB 2.0 with full bandwidth for the coming generations of I/O devices.As all boards in the ETX product line the ETX-PM is fully featured with PCI 2.1 bus, audio, ethernet, floppy/printer, IDE, serial ports and keyboard/mouse interfaces. ETX modules are like components, plugging into an application-specific baseboard. The ETX modules supply the core CPU and memory subsystems together with sound, QXGA, Ethernet and standard PC I/O. They connect to the rest of the embedded system through high density, low profile, surface-mount connectors, which carry both ISA (future option) and PCI bus signals as well as dedicated I/O interfaces. ETX modules are scaleable and interchangeable, and they make possible the rapid development of semicustom solutions for embedded applications.

Alternative Part No. ETX-PM11, ETX-PM, 18008-0000-11-0BR1, 18008-0000-11-0GE1, 18008 0000 11 0

Product Manual

kontron 18008-0000-11-0 dS 1‍ ‍kontron 18008-0000-11-0 dS 2

Product Images
